Disclaimer: this entire post is either a) speculation, b) aspiration or c) incrimination.

Introduction: criticisms of Objective-C

Programmers, onlookers and pundits have criticised Objective-C for longer than Apple has been using it.

If the criticisms were valid and pressing, most could actually be addressed without replacing Objective-C/Cocoa.

Fixable complaints in the language and APIs include the lack of tuples, slices, maps or associations at a syntax level; the lack of template programming; the lack of namespaces; the lack of default parameters to methods; the lack of operator overrides/overloading; leaks and premature collection by the garbage collector (or lack of garbage collection on iOS platforms); the wordy, camel-coded naming conventions; the lack of package management; the lack of out-of-the-box support for "business" APIs like REST, SOAP, SQL, etc. Even the commonly mocked square bracket method invocation syntax could be changed (or supplemented) if the need existed.

None of these criticisms in isolation is a reason to replace Objective-C. All you could argue is that if Objective-C actually needed to change all of these points, then perhaps you might as well replace the entire language.

But replacing the primary application programming language is a jarring task for a development community (especially one that has only just given up on Carbon) and Apple wouldn't do it to address aesthetic issues or minor features. The reasons for replacing a language would need to be more pragmatic and functional.

More relevant in the long term is the one feature that Objective-C can't remove or fix: complaints about C itself, in particular C pointers.

While code level compatibility with C is arguably Objective-C's best feature, it is also the source of Objective-C's most unpopular feature: the direct memory model.

Direct access memory models are a shrinking market

You can't stop the shift away from direct access memory models like the one use in C language; they're simply losing popularity.

According to this list of top 20 most popular programming languages (not exactly a scientific source but it will suffice) only 32% of people still use a language with a direct memory model (C, C++, Objective-C, Pascal and Delphi). In 10 years time, you probably won't see direct memory models used in new projects outside of kernels, drivers, computer games and low-level embedded software.

This means that whether or not Apple deprecate their direct memory model APIs (they probably won't), and whether or not they introduce a new language, Apple will introduce an official application environment with an abstracted memory model.

The role of an application virtual machine in memory abstraction

Technically, Objective-C's current garbage collector is an abstracted memory model. But I'm excluding it from consideration because it's not a complete abstraction and it never will be while Objective-C contains C pointers.

Just because you don't need to release your memory, doesn't mean there aren't other memory problems. You still have pointers. These pointers can still point to anything. You still have C arrays that you can overrun. You can still have buffer overflows. You can still accidentally overwrite sections of memory. There are even situations where you can get the garbage collector to collect memory that you're still using.

That's a pretty leaky abstraction.

It is possible to create a memory model abstraction without using a genuine virtual machine (see A Different Path, below) but a virtual machine allows you to lock down the abstraction so that there aren't any accidental loop holes. You no longer need pointers. You can't simply overwrite memory. You can't overrun arrays. You can't overflow buffers.

The virtual machine does this by removing instructions that offer direct access to memory. Instead, the instructions on the machine relate to objects, properties and values — you cannot access the wrong piece of memory and garbage collection can be precise rather than conservative because all memory references are known absolutely.

Clarification on what I mean by virtual machine: A virtual machine is a description of a computer that is not directly tied to any specific computer implementation but instead can be mapped onto an actual machine. This mapping is normally either through runtime interpretation (like a scripting language), runtime simulation (like a computer emulator) or just-in-time compilation into native machine code (like Java's JVM). Regardless of how the virtual machine is run, the point is that the programmer only ever deals with this virtual scenario and the exact architecture and behaviors of the target machine are never directly accessed.

Platform independence

A second argument for a virtual machine is actually unrelated to the language considerations: platform independence.

Apple have already switched CPU architectures twice in 17 years. It will almost certainly happen again. While the transition to Intel CPUs was unbelievably smooth (I remain stunned about how seamless it was) there was still a significant wait for Intel-native versions of many programs and significant cost to Apple and other developers to make the whole transition work.

With Apple's additional focus on iOS devices, it's also possible to imagine a range of different CPUs could be used across a single lineup and fat binaries (such as the existing armv6/armv7 iOS binaries) are only convenient for a small number of CPUs. If Apple wanted to use a dozen different CPUs, a single bytecode runtime would be the only way.

Wherever possible, good programming generally avoids coding to specific hardware components. Abstracting the CPU and the platform away from our programs is simply a logical step along the same lines.

On the topic of running across different CPUs, an interesting point to consider is that Apple actually did recently introduce a new, platform independent language that runs in JIT compiled virtual machine: OpenCL. I don't foresee any push to re-implement Cocoa in OpenCL (it's way more cryptic than Objective-C) but the technology to do these things certainly exists.

Virtual machine without a new language

An important point to note is that the introduction of a virtual machine could preceed a new language.

If Apple decided that fear of manual memory management was keeping good programmers away but wasn't ready to actually transition to a new language in one leap, it would be possible to transition to the virtual machine first (and gain many of the memory abstraction advantages) while keeping the code-level changes relatively minor.

While this might seem like a thoroughly strange thing to do, it does have a couple advantages.

The first is that an implementation of Objective-C adapted to run inside a virtual machine would be easier to bridge to native Objective-C outside the virtual machine. If you remember Apple's retired effort at bridging Java and Objective-C, the biggest technical difficulty was that Java's view of an object is less runtime dynamic than that of Objective-C and Java had difficulty keeping track of method and isa pointer changes on the Objective-C side. Bridging a virtual machine language to its non-virtual machine equivalent would be easier on this modelling level.

The second advantage of keeping Objective-C during the transition to a virtual machine is that Cocoa is currently written to match Objective-C's feature set. Cocoa might be able to remain substantially similar, making Apple's work upfront much easier.

Update: Jesper has responded to this point and explained why virtualizing Objective-C while keeping some level of compatibility with non-virtualized Objective-C is probably not a good idea.

In short: a virtualized version of Objective-C would (like C++.NET before it) need to have a number of language features removed (to the point where it is not source compatible enough to matter) or it would need to throw runtime exceptions all over the place if your code violated a long list of rules (which doesn't solve the memory abstraction problem it just hurts you if you get it wrong).

A different path

Of course, just because the above advantages exist, doesn't mean that a virtual machine environment is a guaranteed next step in Mac programming evolution.

There do exist compiled, garbage collected, memory safe languages that don't require virtual machines but would satisfy the requirement of a totally abstracted memory model. Google's Go language is one example.

It is unlikely Apple would literally adopt Go. Aside from the fact that Go is still a work in progress, there is also the problem that Go (and most other languages) are not interoperable or bridgeable with Objective-C classes (again this is why bridging Java to Objective-C was problematic — the runtimes need to be significantly compatible). In fact, Go does not yet easily bridge to C or C++, yet.

Actually moving to a Go-like language would require a clean break with no backwards compatibility. While a clean break is not impossible (Carbon to Cocoa was a clean break), I think it more likely that Apple would choose to keep some amount of interoperability by either using a custom language — or a custom variation of an existing language — that uses a runtime closer to Objective-C. The reason why I suspect this is that Apple have already had the chance to replace Cocoa (with iOS) but chose to keep largely the same design — I suspect that they'd choose to keep Cocoa into the future on the Mac, even if the language or environment changes.

The greater possibilities of backwards compatibility, bridging and portability afforded by virtual machines, and the excellent performance of modern JIT implementations, lend me to think that a non-virtual machine option doesn't provide enough flexibility and advantages for the next isn't a compelling enough to warrant the pain of a language transition.

Conclusion

Obviously, I like Objective-C and Cocoa; I'm sure that much is clear from the existence of this blog and my posts defending its traits. I don't agree with most of the criticisms that I've listed in this article — for the most part, I think the criticisms are either trivialities or they're philosophically and technically misguided.

But Mac programmers can't fight against an overwhelming trend towards totally abstracted memory models that's largely happening outside the borders of Mac programming.

Furthermore, I don't think the eventual move towards an application virtual machine is a change that needs to be fought. Most of what currently defines Cocoa and Mac programming — the attention to detail, the way widgets, methods, classes and APIs all work well together won't change. In fact most of Cocoa might actually stay the same.

Eventually though, I'm sure Apple will switch to a new programming language; fashions change and a new language is always refreshing (if a little weird in the beginning).

There really isn't a rush to do this though. Certainly iOS devices don't need the performance hit right now. But even on the Mac I think there will be a few years warning before anything happens and no forced transition when it finally does.

When I say there isn't a rush: I mean it. I think its probable that you will still be able to release new, non-virtual-machine, Cocoa/Objective-C programs for the Mac OS du jour in 10 years time (in the same way that you can still write Carbon programs today if you choose). I just don't think it will be the most common choice.

A project or target that supports multiple versions of iOS

To make an application target that runs on multiple versions of iOS is relatively simple:

• Set the "Base SDK" in your projects settings to the newest version number of iOS whose features you may want.
• Set the "iPhone OS Deployment Target" to the oldest version number of iOS that you will support

However, getting the target settings correct is the easy part of the problem. The hard part is using new features on newer iOS versions without breaking the app on older versions.

Running in the 3.1.3 simulator

Before getting to the actual code, it might be worthwhile to discuss how to run your projects in older versions of the simulator.

The simulator is an important part of iOS development (since it is much faster and simpler than running your code on the device). But Apple have removed SDK versions earlier than 3.2 from the current Xcode builds. This makes it hard to verify your apps on earlier devices unless you install on a physical device.

Support for 3.1.3 is relatively important since it is the last version of iOS supported by the original iPhone and iPod Touch and it will be a few months before iOS 4 exceeds 80% of the remaining iPhone and iPod Touch market.

To allow simulation in 3.1.3, you must install an old version of Xcode. If you are a registered iPhone developer, you can download Xcode 3.1.4 for Leopard with iPhone SDK 3.1.3 or Xcode 3.1.4 for Snow Leopard with iPhone SDK 3.1.3. Be careful to install these in a different location to your Xcode 3.2.3 with iOS3.2/iOS4 (either select a different hard disk or rename your existing /Developer directory before you install).

Once you've got an old version of Xcode, you'll want to duplicate your main target and set the Base SDK to 3.1.3 in this duplicate (because it won't exist in this version of Xcode). You should use a second target for this because you shouldn't risk messing with your main target just to run code in the simulator.

Using features from newer iOS versions while supporting older iOS versions

For example, if you want to start an iOS4 background task in an application that you want to run on earlier versions of iOS, then you'll need to use code like this:

#if __IPHONE_OS_VERSION_MAX_ALLOWED >= 40000
    if ([[UIApplication sharedApplication]
        respondsToSelector:@selector(beginBackgroundTaskWithExpirationHandler:)])
    {
        UIBackgroundTaskIdentifier bgTask = [[UIApplication sharedApplication]
            beginBackgroundTaskWithExpirationHandler:^{}];

        // Perform work that should be allowed to continue in background

        [[UIApplication sharedApplication] endBackgroundTask:bgTask];
    }
#endif

There are three important components:

1. The #if __IPHONE_OS_VERSION_MAX_ALLOWED >= 4000 compile-time conditional. This ensures that if we choose to build this project with a Base SDK lower than 4.0, then it won't cause compile problems. This is essential for running in older versions of the simulator.
2. The runtime check that UIApplication supports the beginBackgroundTaskWithExpirationHandler method. Since the final release build will be built against the 4.0 SDK (even if users install on SDK 3.0) this runtime check ensures that the method we need is available.
3. Everything else between the #if __IPHONE_OS_VERSION_MAX_ALLOWED >= 4000 and the #endif is the iPhone OS 4 code.

Making the conditional work less ugly

The problem with the previous code is the compile-time conditional and the runtime check for the presence of methods is cumbersome since you must remember to to both.

If you want to integrate both a compile-time check and a runtime check, a better approach would look like this:

IF_IOS4_OR_GREATER
(
    UIBackgroundTaskIdentifier bgTask = [[UIApplication sharedApplication]
        beginBackgroundTaskWithExpirationHandler:^{}];

    // Perform work that should be allowed to continue in background

    [[UIApplication sharedApplication] endBackgroundTask:bgTask];
);

We can implement this macro as follows:

#ifndef kCFCoreFoundationVersionNumber_iPhoneOS_4_0
#define kCFCoreFoundationVersionNumber_iPhoneOS_4_0 550.32
#endif

#if __IPHONE_OS_VERSION_MAX_ALLOWED >= 40000
#define IF_IOS4_OR_GREATER(...) \
    if (kCFCoreFoundationVersionNumber >= kCFCoreFoundationVersionNumber_iPhoneOS_4_0) \
    { \
        __VA_ARGS__ \
    }
#else
#define IF_IOS4_OR_GREATER(...)
#endif

If we want to include something only in OS versions prior to a a specific version, then we don't need the conditional compilation (since we still want the code to appear when compiled in a later version. In this case, only a runtime check is required. You can either do this directly, or for symmetry with other macros, you could use:

#define IF_PRE_IOS4(...) \
    if (kCFCoreFoundationVersionNumber < kCFCoreFoundationVersionNumber_iPhoneOS_4_0) \
    { \
        __VA_ARGS__ \
    }

Three interesting points to note about these macros:

1. I use the kCFCoreFoundationVersionNumber to determine the iPhone OS at runtime. There are many examples on the web using [[UIDevice currentDevice] systemVersion] but that method requires a string comparison and potentially handling of major and minor numbers within the string components. A single double comparison is far more straightforward.
2. I have not used the typical do { x } while (0) wrapper around the macro, so you can simply tack an else onto the end if you choose (and it doesn't need conditional compilation of its own).
3. I use a variable argument list for the macro. This is so that any number of commas may appear in the contents without causing problems.

A final point... the kCFCoreFoundationVersionNumber definitions may not be in every version of the SDK (each SDK normally contains definitions for versions up to but not including itself), so you should conditionally define them yourself in case they're missing. Here's a handy list:

#ifndef kCFCoreFoundationVersionNumber_iPhoneOS_2_0
#define kCFCoreFoundationVersionNumber_iPhoneOS_2_0 478.23
#endif

#ifndef kCFCoreFoundationVersionNumber_iPhoneOS_2_1
#define kCFCoreFoundationVersionNumber_iPhoneOS_2_1 478.26
#endif

#ifndef kCFCoreFoundationVersionNumber_iPhoneOS_2_2
#define kCFCoreFoundationVersionNumber_iPhoneOS_2_2 478.29
#endif

#ifndef kCFCoreFoundationVersionNumber_iPhoneOS_3_0
#define kCFCoreFoundationVersionNumber_iPhoneOS_3_0 478.47
#endif

#ifndef kCFCoreFoundationVersionNumber_iPhoneOS_3_1
#define kCFCoreFoundationVersionNumber_iPhoneOS_3_1 478.52
#endif

#ifndef kCFCoreFoundationVersionNumber_iPhoneOS_3_2
#define kCFCoreFoundationVersionNumber_iPhoneOS_3_2 478.61
#endif

#ifndef kCFCoreFoundationVersionNumber_iPhoneOS_4_0
#define kCFCoreFoundationVersionNumber_iPhoneOS_4_0 550.32
#endif

Better still: solutions that don't require macros

Better than a simple macro is a simple function. This is a valid solution where the contents of your conditional code does not itself contain OS specific code (only the condition itself requires OS specific logic).

A common example is handing separate layout for iPad and iPhone versions. Ordinarily, if you're compiling for iPad 3.2 and iPhone 3.1.3, you need the following code:

#if __IPHONE_OS_VERSION_MAX_ALLOWED >= 30200
    if ([[UIDevice currentDevice] respondsToSelector:@selector(userInterfaceIdiom)] &&
        [[UIDevice currentDevice] userInterfaceIdiom] == UIUserInterfaceIdiomPad)
    {
        // iPad specific layout changes
    }
    else
#endif
    {
        // iPhone layout
    }

You can handle this with a conditional macro like the IF_IOS4_OR_GREATER but a far better solution is:

if (isIPad())
{
    // iPad specific layout changes
}
else
{
    // iPhone layout
}

Where all the conditional pollution is tidily kept in your isIPad() function:

BOOL isIPad()
{
    IF_3_2_OR_GREATER
    (
        if ([[UIDevice currentDevice] userInterfaceIdiom] == UIUserInterfaceIdiomPad)
        {
            return YES;
        }
    );

    return NO;
}

Conclusion

Apple doesn't exactly make it easy to support old versions of the iPhone SDK. I'm sure they want everyone to keep up to date or buy new devices if their current device can't be updated.

That's not always a realistic attitude for App Store developers. You can't expect all your customers to upgrade as soon as possible.

The important point when writing for multiple versions of the SDK is to keep as few conditionals as possible. You don't want to have thousands of conditionals in your code for supporting different versions. Every conditional is extra testing work since different behaviors must be fully exercised on all different platforms.

While the conditionals and functions I've talked about here will help, if you find yourself needing a lot of conditionals you may also want to consider design changes like instantiating different subclasses for different OS versions.

Scope of this article: in this post I'll be discussing basic memory and mutability considerations in Objective-C accessor methods. If you're interested in atomicity and thread safety issues in accessor methods, please read my earlier post on Memory and thread-safe custom property methods. This post will only look at non-atomic accessors.

Why implement your own accessors?

If you know about Objective-C's properties, you may already be asking, "Why implement your own accessors at all?". For simple accessors, you can (and probably should) use the synthesized @property accessors and not worry about the implementation. The reason for this post is that you will often need to implement accessor methods yourself to attach additional behaviors to the get or set action, so you always need to know how the accessor should work.

The one you already know: the assign pattern

Since you're reading this blog, it's probably safe to assume that you already know how a basic assign accessor looks:

- (SomeVariable)someValue
{
    return someValue;
}

and a setter method looks like this:

- (void)setSomeValue:(SomeVariable)aSomeVariableValue
{
    someValue = aSomeVariableValue;
}

For most non-object data, that's all you need. This is the implementation you'd get with a non-atomic assign synthesized @property.

Retain: first opportunities for failure

If you're working with retain/released objects in Objective-C, your object will become invalid if your setter does not retain it. A non-atomic setter method that retains its argument looks like this:

- (void)setSomeInstance:(SomeClass *)aSomeInstanceValue
{
    if (someInstance == aSomeInstanceValue)
    {
        return;
    }
    SomeClass *oldValue = someInstance;
    someInstance = [aSomeInstanceValue retain];
    [oldValue release];
}

This would be straightforward if it wasn't for the comparison and the weird retain/release dance. We do this to avoid problems where the object pointed to by aSomeInstanceValue and someInstance is the same. Imagine the following:

- (void)setSomeInstance:(SomeClass *)aSomeInstanceValue
{
    [someInstance release]; // <-- original value is released
    someInstance = [aSomeInstanceValue retain];
}

If aSomeInstanceValue and someInstance are the same object, then the first line could release the underlying object before the second line retains it.

You'll notice that we use the C equality operator to compare the two objects instead of the isEqual: method. Normally, this is a bad idea (Objective-C objects may be "equal" even if they do not point to the same location in memory) but in this case, we are specifically interested in cases where the memory location (and hence the retain counts) are identical. The comparison is not strictly necessary to prevent premature release (since the retain precedes the release) but it's an optimization and safety measure.

Not all Objective-C setters should retain: There are some situations where a setter method that takes an Objective-C object should not retain its parameter. Specifically: objects in a hierarchy should not normally retain their parents. Look at Rules to avoid retain cycles for more on this topic.

The other half of the retain access pattern

In reality, even if you forget to perform the if (newInstance == oldInstance) return; check in your accessor method, you are highly unlikely to see a problem even if you actually do pass the current value to a setter method.

The reason why you are normally safe, even if you make a mistake, is because the parameter you pass into a method normally has another retain count held elsewhere.

Specifically: most objects you access on the stack have an autoreleased retain count held by an autorelease pool on the stack or a longer lived object somewhere in the heap.

Theoretically, you could help this idea along by implementing your getter methods like this for retained objects:

- (SomeClass *)someInstance
{
    return [[someInstance retain] autorelease];
}

This will ensure that if your object is used like this:

SomeClass *stackInstance = [anObject someInstance];
[anObject release]; // anObject releases its someInstance ivar in its dealloc method
[stackInstance doSomething];

Then the stackInstance variable will still be valid when doSomething is invoked on it.

Generally though, I don't bother doing this in non-atomic getter methods.

Why not? Speed, redundancy and common sense.

While retaining and autoreleasing something is not a gigantic overhead, it is normally just not needed for a get accessor method. The programmer using the get accessor should understand that the lifetime is bound to the source object.

However, you may want to use this pattern in a situation where it is not immediately clear that the value returned is a getter method. For example:

@implementation ThisClassIsReallyJustAString

- (NSString *)description
{
    return [[internalValue retain] autorelease];
}

@end

The description method (which returns an NSString representation of an object) does not normally return an instance variable directly so it would not ordinarily be considered an accessor method. In this situation, it is implemented as an accessor but due to the expectation that the description is a generated value, we need to retain and autorelease the returned value.

Any instance variable returned from a method where the method is not obviously an accessor method should always go through a retain/autorelease since it is not immediately obvious that its lifetime would be bound to the lifetime of the source object.

Copy accessors

The reason why retain accessors exist is obvious — you don't want the value to be deallocated while it is set on the object.

The reason for the final accessor pattern in Objective-C — copy accessors — is less broadly understood but nonetheless relevant.

You should use a copy accessor when the setter parameter may be mutable but you can't have the internal state of a property changing without warning. Consider the following example:

NSMutableString *mutableString = [NSMutableString stringWithString:@"initial value"];
[someObject setStringValue:mutableString];
[mutableString setString:@"different value"];

In this situation, if the setStringValue: method followed the retain pattern, then the setString: method invoked on the next line would change the internal value of this property without warning someObject.

Sometimes, you don't care if the internal state of a property change without warning. However, if you do care about the internal state of a property changing, then you'll want to use a copy setter.

The implementation of a non-atomic copy setter is as simple as you'd imagine:

- (void)setStringValue:(NSString *)aString
{
    if (stringValue == aString)
    {
        return;
    }
    NSString *oldValue = stringValue;
    stringValue = [aString copy];
    [oldValue release];
}

Correction: I had previously stated that you don't need the equality comparison for a copy (since I wrongly claimed the copy would ensure you always have a different block of memory). I was wrong, of course. As was immediately pointed out in the comments: copy does not always return a copy; for immutable objects, copy can return the same object. I knew this but inexplicably chose to forget. The result is that we still need the comparison to ensure that setting the property to the same value doesn't cause the same potential release problems that the previous retain pattern had. Did I mention its possible to screw up property accessors?

This finally explains why NSDictionary copies its keys.

NSDictionary stores all its value objects in locations according to the result of each corresponding key object's hash method.

If a key object were to change in such a way that the hash method result changed, then the NSDictionary would not be able to find the corresponding value object any more.

Key objects are not set by a property accessor on an NSDictionary but the effect is the same: the copy pattern is used to ensure that outside objects cannot change the internal state of the dictionary without warning.

Of course, the downside to properties that follow the copy pattern is speed. It's not normally an issue for objects up to a few kilobytes but beyond that point, you'll need to consider whether copy is the right pattern for the resources involved.

Conclusion

Getter and setter methods are frequently given as the simplest kind of method to implement. But you can see that even within this very simple kind of method, there are subtle ways that they can go wrong.

Overall, this post is a much simpler level than my typical posts but that doesn't mean its only for novice Objective-C developers. Experienced programmers are far from immune to mistakes in this area. Some of the potential quirks with getter and setter methods are so rare you may never see a problem (even if your code is doing things in an unsafe manner) so learning from experience can take time in this area.

Of course, if you don't need any customization in your accessor methods, you should simply use a synthesized @property implementation. This will avoid any possibility of introducing mistakes.

Ontology

It would be a mis-statement to claim that all applications have the same design but it is accurate (although more confusing) to state that all well-designed applications share a very high degree of ontological similarity.

Ontology is a pretty obscure word so it might be a good idea to explain it here. I'm going to use an analogy...

When you have a lot of items, it's helpful to classify them into a structure to understand how they relate to each other. For example: all living species on Earth are classifed into Domain, Kingdom, Phylum, Class, Order, Family, Genus and Species. We often just talk about animal or plant "species" but the classification system has many more levels (in fact, there are many more levels in-between these simple names that I've listed). The classification of living things is an example of a "taxonomy" (classifying things into a single hierarchy).

Similarly, every class in a well-designed application can be classified. But the classification of an application isn't a simple tree structure — there are many different connections. And the connections aren't simply of heredity — there are subclasses, view hierarchies, event hierarchies, control hierarchies and more.

When each classified element may have more than one position in the tree, and when different connections may have different semantic meanings and the overall organization isn't a simple tree but it's more of a big ball of wibbly-wobbly, interconnected stuff — that's an ontology.

The ontology of an application

Due to the interconnected, non-simple structure of ontologies, it's difficult to give a simple diagram that fully models one. Instead, I'm just going to list the broad categories of classes that you find in an application and simply discuss how they actually interconnect.

The basic categories of class in an application ontology.

This diagram describes pretty much every class type you're likely to see in an application. In a well designed project, these are the names of the Groups in the class tree.

Where did I get this list? I've really just transcribed the Groups from some of my larger projects. If you're interested, I consider a large project to be approximately a couple hundred classes. The largest I've ever let a project get is just over 400 classes. Normally, as a project gets near that size, I break it apart into multiple sub-projects. Generally, in a break apart like this, the "application" stays where it is and the "document" or "job handler" components get spun out into their own projects.

Breaking a huge project into pieces offers lots of advantages: it makes building faster, forces better abstraction and interfaces and makes testing easier (because the interface between components is a great place for system tests). The drawback is that the build process and version management can get a little trickier but once the project becomes that big, you normally have a good process in place to handle that complexity.

Applications on other platforms: While applications on different operating systems share much in common, the description here applies most accurately to Cocoa Mac applications. The needs of interacting with different application frameworks and delivering different features to users on different platforms ultimately effect the ontological structure of the application's classes.

Application initiation, top level control, configuration

In a Cocoa program, this includes the main.c file and your App Delegate. In a Cocoa Mac document-based application, this also includes the NSDocumentController.

These classes perform startup and top-level handling and shouldn't do anything else.

A good indication of a hastily or poorly written application is when other functionality gets implemented in one of these classes. Since these classes are almost always present and are accessible at the top level, it's easy to be lazy and shove functionality into them because the functionality doesn't seem to fit elsewhere.

View and event hierarchies for primary workflow

This includes your primary NSDocument subclass, your NSWindowContorllers, NSViewControllers, UIViewControllers and the primary (used for displaying the main document) NSViews or UIViews.

In a simple application that does more browsing than processing, this will be the bulk of the project. Fortunately, the view hierarchy is typically highly structured. Controllers at the top and nested views all the way down.

New communication between view elements should go through the top controller of any hierarchy or should through connections established by a higher level of the hierarchy. Views talk to corresponding document objects but the correspondence should be entirely established by the controllers.

The view and event hierarchies are generally similar; the few differences there are likely to be will rarely cause a problem.

View and event hierarchies for secondary workflows

An example of a secondary workflow would be the downloading interface in a web browser — a fully contained user-interface that runs in a different view or window. It also includes complicated popup/modal or other interfaces like the "Get Info" interface in the Mac OS X Finder or the "Add to Playlist" functionality in the iPod app on the iPhone.

These tend to run like separate little programs within the greater application and you should write them as such. While they may share some views and data with the rest of the program, they generally use their own controllers to manage the workflow and as such should not simply be lumped in with the classes from the main workflow.

Data processing and handling

This is your "document" (or "model" in MVC parlance). In a basic application, the document may be vanishingly small (a single array of objects or even a single object). For the largest applications though, the document is generally the majority of the program.

Generally, the document includes an interface at the top level that connects it to the structure of the rest of the program — since the elements within the document should be as ignorant of the structure of the rest of the program as possible. This connective interface is sometimes rolled into the NSDocument class on the Mac (which is also the controller of the document's view hierarchy). That's not too bad (they're both controllers) but in larger programs, the connecting controller for the document's view and the document's model may end up being different classes.

Below the interface there is normally some form of management or coordination to handle caching, saving, memory and other issues related to the runtime state but not necessarily the persistent state of the document. This is the role that the NSManagedObjectContext performs for a document implemented using Core Data.

Since the document is the part of a program that is not inherently designed following "application" rules, it does not necessarily follow an application ontology. For this reason, you may need to keep diagrams to understand the structure of highly complex document model. Fortunately, if you're using Core Data or another persistence framework for storing your model, you probably already have a diagram of your model.

Activity/job handling and execution

This is a category that unfortunately gets left out of many MVC discussions.

A functional pipeline fulfils a similar role to the document but instead of exposing data storage and manipulation to the user, exposes actions and behaviors.

An example would be a web server. If you push the "Start Server" button in your user interface, that button is not connected to a document but to a top level controller that starts the server. That top-level controller is the interface to a functional pipeline.

In many respects, a functional pipeline should be treated like a document — connect it to views in the same way (through controllers that link values to display) and manage it in the same way (through a top level interface that exposes functionality to the rest of the program).

Preferences, styles and filesystem integration

This layer is largely filled with singletons; independent components that manage a small set of data that can be accessed at will from anywhere in the program.

These types of classes tend to drive Dependency Injection enthusiast Unit Testers crazy because they follow a state-machine rather than a command-pattern (state machines are very hard to unit test).

Settings management is an essential component of larger programs. Basic storage provided by NSUserDefaults becomes insufficient once different parts of the program need to coordinate access to the same settings.

A styles controller is really just a way of accessing the same fonts, colors and other elements that make your program look consistent.

Custom views and control elements

This level is the storage bin for controls and views that are not tied to a specific workflow but (like the Styles Controller) are reused through the program to give a consistent aesthetic and set of behaviors to the use.

Single purpose views generally live along with the workflow that uses them. For this reason, as a program goes, you may continuously generalize your single use views and move them out of a workflow into this more general section.

This level of the application ontology also tends to be the first so far that contains concrete classes that may be brought in from outside the program. While your view controllers or document may include reusable abstract classes, the concrete implementations are normally specific to your program. Custom controls however are easily used in concrete form across a range of different applications.

Programming and testing facilities and integration

This is the cluster of classes that the user should never see (with the possible exception of Error dialogs). Many of the debugging and testing classes simply don't appear in release builds.

Why would kludges, hacks and bug work-arounds appear here instead of closer to the classes they affect? Because they are parts of your code that the developer needs to keep a close eye on and should be able to disable easily in the event that they no longer apply. For these reasons, you should keep them from directly polluting your real code.

Drawing, processing, extensions and patches

These are the type of class that I've shared many times in this blog: handy tricks for accessing or achieving something with little or no dependency on the rest of your application.

While this occupies just a single level of the diagram, in a medium sized program, these classes could be more than half the total classes in the program — little tools, tricks, reusable code and behaviors you like to carry from program to program.

Fortunately, the large number of these classes rarely makes the program more complex — they have no significant connections to the rest of the program. The only difficulty tends to be cleaning them out when they're no longer used.

Scalability

In many situations, the size of a program increases complexity and makes it harder to understand.

For the "application" side of a program (not including the "document"), greater size actually tends to force the program to behave more regularly and fit the categories I've discussed better.

In smaller applications, classes tend to be more multi-functional, spanning many of these categories. As an application grows, classes tend to become more single-functional so they fit the standard categories better.

The "document" — and to a lesser extent, functional workflows — tend to be the exception to this scalability rule, since they don't adhere to a common ontology. You will probably want to model and document your document.

Conclusion

Applications are a relatively narrow domain within programming overall — they need to perform specific functions and tend to perform those functions in similar ways.

This similarity leads them to be structure similarly, to interconnect in similar ways; to share a common ontology.

While the pattern may not be obvious when looking at a large program for the first time, or if you're continuously looking at hastily-constructed, small-to-medium sized projects, applications are structurally simple.

I've drawn a distinction in this post between applications and other types of programs — even between the application part of a program and the non-application parts of a program. Obviously, non-application parts of an application will likely not follow the ontology of an application.

While a badly designed, badly organized project can escape many of the traits you'd normally expect from an application, the mechanics of hooking into a framework like Cocoa and required steps to implement application-like features still dictate a structure that is hard to escape.

Sorting an array

You can sort an NSMutableArray by any logic you want using a comparison method (implemented on the contained objects) and invoking sortUsingSelector: on the array.

What would happen if you sorted an array of numbers using the following category method which returned a random result?

@implementation NSNumber (RandomComparison)

- (NSComparisonResult)randomCompare:(id)other
{
    // randomly return either ascending or descending
    return (random() % 2) ? NSOrderedAscending : NSOrderedDescending;
}

@end

Naively, you might think that the result would be an even, random distribution.

Distribution from a random sort

For an array 20 elements long, sorted using a random comparison, the following is a chart of percentages where the 1st element in the array ended after 1 million runs:

The percentage of times that the original 1st element ended in each position of the final array.

In a proper random distribution, you'd expect the first element to be equally likely to end up in any position. In fact a correct result here should be 5.0% +/- 0.1% for every column.

The actual result reflects traits of NSMutableArray's internal sorting (which I'm presuming uses a sort similar to the CFQSortArray from CoreFoundation.

The biggest feature of the distribution is a fuction of how quicksort works. Between 7 and 40 elements (which this array is), NSMutableArray's sort chooses a single pivot which is most likely to be in the middle of the array. Elements on either half are sorted with respect to each other before sorting with the whole.

This pivot selection causes the huge difference between the distribution in the top and bottom half since elements compared with other elements on their own side of the pivot more often, they are more likely to remain on that half of the pivot.

Quicksort subdivides the array but for subdivided blocks smaller than 7 elements, the NSMutableArray's sort algorithm uses a bubble sort instead of quicksort. Elements 1 to 5 at the far left of the distribution show what happens in this bubble sort case: a bulge in the center of the 1 to 5 range, skewed in the direction of the element's original position (i.e. the bulge is lopsided towards 1).

Let's look at what happens to element 11:

The percentage of times that the original 11th element ended in each position of the final array.

This is not a simple mirror of the previous results but it again follows the quicksort pattern: results from a random sort are most likely to stay in the partition where they began, with minor perturbations on the fringes due to the bubble sort.

The correct way to randomize in-place

If you're interested, the correct way to randomize in-place is:

@implementation NSMutableArray (Randomization)

- (void)randomize
{
    NSInteger count = [self count];
    for (NSInteger i = 0; i < count - 1; i++)
    {
        NSInteger swap = random() % (count - i) + i;
        [self exchangeObjectAtIndex:swap withObjectAtIndex:i];
    }
}

@end

A quick summary of what this does:

1. conceptually split the array into "used" elements (in their final positions) and "unused" elements (initially, everything is "unused")
2. randomly choose an element from the unused elements
3. swap the chosen element with the first element in the unused range
4. this first position in the unused range is now considered used (i.e. the element is in its final position)
5. repeat steps 2 to 4 until all elements are in their final positions

This algorithm is the "Fisher–Yates shuffle" and dates to 1938 (which is an indication of how obvious it is).

If you're truly interested in a perfectly even, random distribution, you may want to use an approach that avoids biases due to modulo (modulo will round down too often for non-binary divisible numbers). You can see one approach for unbiased rounding in this post by Brent Royal-Gordon on StackOverflow. Although if you're really interested in an even distribution, you'll probably want to use a Mersenne-Twister instead of the C random() function.

The reality is that that code I showed is faster than the other options and easily good enough unless you have a strong mathematical need for accuracy (in my tests on 1 million samples, it was evenly distributed to 2 significant figures in all cases).

Conclusion

A quick post this week. I was really just goofing around with comparison methods and thought the results were interesting. In retrospect, its obvious that the results from a sort with a random comparison would be a function of how the sort is performed but I was surprised that the two different kinds of sort (bubble and quick) both had a visible influence on the results.

Of course, there are proper ways to randomize arrays and they're not very difficult — unless you're really fussy about the quality of your random numbers.

Introduction: libdispatch's global queue is a constrained resource

In Mac OS X 10.6 (Snow Leopard), Apple introduced Grand Central Dispatch (GCD) for managing a system-wide thread pool. The normal API for GCD is libdispatch (despite the name, this API is part of libSystem).

The simplest way to interact with libdispatch is to execute blocks on the global queue:

dispatch_queue_t queue = dispatch_get_global_queue(DISPATCH_QUEUE_PRIORITY_DEFAULT, 0);
dispatch_async(queue, ^{ /* perform some work */ });

For discrete packets of work that are not order dependent, this is a great solution. In this post, however, I'm going to look at situations where this is a poor choice.

The key limitation of this approach is that the global concurrent thread pool is a constrained resource — there are only as many active threads in this pool as you have CPUs on your computer.

Using this constrained resource indiscriminately can lead to the following problems once the limits of the resource are reached:

• higher latency than other solutions
• deadlocks for interdependent jobs in the queue

Latency problems

The following code simulates a tiny web sever or similar program that needs to serve a number of clients. In this case, it has 20 simultaneous requests from different clients.

In reality, this program just writes a small string to /dev/null 100,000 times for every client but that's sufficient to simulate any similar network or other non-CPU based operation.

int main(int argc, const char * argv[])
{
    dispatch_queue_t queue = dispatch_get_global_queue(DISPATCH_QUEUE_PRIORITY_DEFAULT, 0);
    dispatch_group_t group = dispatch_group_create();

    FILE *devNull = fopen("/dev/null", "a");

    const int NumConcurrentBlocks = 20;
    const int NumLoopsPerBlock = 100000;

    for (int i = 0; i < NumConcurrentBlocks; i++)
    {
        dispatch_group_async(group, queue, ^{
            NSLog(@"Started block %d", i);
            for (int j = 0; j < NumLoopsPerBlock; j++)
            {
                fprintf(devNull, "Write to /dev/null\n");
            }
            NSLog(@"Finished block %d", i);
        });
    }

    dispatch_group_wait(group, DISPATCH_TIME_FOREVER);
    dispatch_release(group);
    fclose(devNull);

    return 0;
}

This scenario illustrates the latency problems inherent in using the libdispatch global queue: on my computer, the first 4 blocks start immediately and the first of these finish 1.5 seconds later when the next blocks are started. The final block does not begin until 7.5 seconds after it is queued, finishing at the 9 second mark.

While the global queue in libdispatch is called "concurrent", it is only concurrent up to a threshold. Once the concurrent slots are full, the global queue becomes serial — in this case, the limit is reached and the serial nature increases the latency.

If this were a heavily loaded web server, instead of simply slowing down evenly for all users, the first few users would get a response and the last few would simply time out.

The solution to this type of problem is to create a specific queue for every block. Instead of pushing everything into the global queue (which is capped at 4 blocks on my test computer) we will have a separate queue for each block that will run simultaneously.

int main(int argc, const char * argv[])
{
    dispatch_group_t group = dispatch_group_create();
    FILE *devNull = fopen("/dev/null", "a");

    const int NumConcurrentBlocks = 20;
    dispatch_queue_t *queues = malloc(sizeof(dispatch_queue_t) * NumConcurrentBlocks);
    for (int q = 0; q < NumConcurrentBlocks; q++)
    {
        char label[20];
        sprintf(label, "Queue%d", q);
        queues[q] = dispatch_queue_create(label, NULL);
    }

    const int NumLoopsPerBlock = 100000;
    for (int i = 0; i < NumConcurrentBlocks; i++)
    {
        dispatch_group_async(group, queues[i], ^{
            NSLog(@"Started block %d", i);
            for (int j = 0; j < NumLoopsPerBlock; j++)
            {
                fprintf(devNull, "abcdefghijklmnopqrstuvwxyz\n");
            }
            NSLog(@"Finished block %d", i);
        });
    }

    dispatch_group_wait(group, DISPATCH_TIME_FOREVER);
    dispatch_release(group);
    fclose(devNull);

    return 0;
}

The result is that all 20 blocks are started simultaneously. All run at approximately the same speed and all finish at approximately the same time.

Alternative solution: as suggested by Keith in the comments, since these operations are I/O bound, not CPU bound, a better solution would be to use a file write source in the queue instead of standard operation queue blocks. File write sources are removed from the queue when they are blocked on I/O and this would allow all 20 sources to operate equitably in the global concurrent queue (or any other single queue).

Deadlocking

Deadlocking occurs when a first block stops and waits for a second to complete but the second can't proceed because it needs a resource that the first is holding.

In the following program, 20 parent blocks are queued (which will more than fill the constrained resource of the global concurrent queue). Each of these blocks spawns a child block which is queued in the same global concurrent queue. The parent runs a busy wait loop until the child adds its own integer to the completedSubblocks set.

NSMutableSet *completedSubblocks;
NSLock *subblocksLock;

int main (int argc, const char * argv[])
{
    completedSubblocks = [[NSMutableSet alloc] init];
    subblocksLock = [[NSLock alloc] init];

    dispatch_queue_t queue = dispatch_get_global_queue(DISPATCH_QUEUE_PRIORITY_DEFAULT, 0);
    dispatch_group_t group = dispatch_group_create();

    const int NumConcurrentBlocks = 20;
    for (int i = 0; i < NumConcurrentBlocks; i++)
    {
        dispatch_group_async(group, queue, ^{
            NSLog(@"Starting parent block %d", i);

            NSDate *endDate = [NSDate dateWithTimeIntervalSinceNow:1.0];
            while ([(NSDate *)[NSDate date] compare:endDate] == NSOrderedAscending)
            {
                // Busy wait for 1 second to let the queue fill
            }

            dispatch_async(queue, ^{
                NSLog(@"Starting child block %d", i);

                [subblocksLock lock];
                [completedSubblocks addObject:[NSNumber numberWithInt:i]];
                [subblocksLock unlock];

                NSLog(@"Finished child block %d", i);
            });

            BOOL complete = NO;
            while (!complete)
            {
                [subblocksLock lock];
                if ([completedSubblocks containsObject:[NSNumber numberWithInt:i]])
                {
                    complete = YES;
                }
                [subblocksLock unlock];
            }

            NSLog(@"Finished parent block %d", i);
        });
    }

    dispatch_group_wait(group, DISPATCH_TIME_FOREVER);
    dispatch_release(group);

    [completedSubblocks release];
    [subblocksLock release];

    return 0;
}

On my computer the first 8 blocks are started (filling the global queue's concurrent blocks) and these blocks block the global queue so that the child blocks can never run. Since the parent is waiting for the child and the child can never run, the result is a deadlock: the program never completes.

You'll notice that I've used a busy wait loop for both the 1 second delay and to detect when the child has completed. Normally, you would dispatch the child using dispatch_sync (which is a different way to wait for the child to complete) but the reality is that libdispatch is smart enough to remove a block from its queue while it is using one of the libdispatch wait mechanisms (or one of the many Cocoa or OS functions that similarly yields CPU time like sleep).

While using the correct functions to wait will fix this trivial example, it will not fix the situation where the processes might be genuinely busy.

The best solution is to avoid dependencies between blocks in the same queue.

In a situation like this where one of the blocks (the child block) consumes a trivial amount of time and the other is time consuming (the parent always takes at least 1 second), you can simply enqueue the trivial time block in a separate serial queue. That will prevent deadlocking in all cases.

In a situation where both parent and child are time consuming, you could try:

• create a separate queue for every invocation of either the parent or child and queue the other in the global queue
• roll the functionality of the child into the parent so that they are always done as a single block
• carefully write your code to ensure that a libdispatch wait mechanism is always ahead of any dependency

Conclusion

While libdispatch does an excellent job at making concurrent, multithreaded programming easier, it does not magically eliminate some of the pitfalls.

The problems I've looked at in this post are mostly a result of the fact that queues are shared resources and there are situations where you must be careful about how resources are shared.

Grand Central Dispatch's global queue is intended for CPU intensive operations. That it limits concurrency to the number of CPUs in your computer is good for CPU intensive operations; it prevents wasting CPU time due to task swapping. The examples here demonstrate the downside: it may increase latency for queue blocks and you need to be careful about dependencies between blocks on the same queue.

Introduction

This post will present a sample application that deliberately raises Objective-C exceptions, EXC_BAD_ACCESS exceptions and related BSD signals. All exceptions and signals are caught, presenting debug information and allowing the application to continue after these events.

You can download the sample project: UncaughtExceptions.zip (25kB)

This application will deliberately trigger an unhandled message exception after 4 seconds and then will deliberately trigger an EXC_BAD_ACCESS/SIGBUS signal at the 10 second mark.

Why do applications crash on the iPhone?

A crash (or more accurately: an unexpected termination) is the result of an unhandled signal sent to your application.

An unhandled signal can come from three places: the kernel, other processes or the application itself. The two most common signals that cause crashes are:

• EXC_BAD_ACCESS is a Mach exception sent by the kernel to your application when you try to access memory that is not mapped for your application. If not handled at the Mach level, it will be translated into a SIGBUS or SIGSEGV BSD signal.
• SIGABRT is a BSD signal sent by an application to itself when an NSException or obj_exception_throw is not caught.

In the case of Objective-C exceptions, the most common reason why unexpected exceptions are thrown in Objective-C is sending an unimplemented selector to an object (due to typo, object mixup or sending to an already released object that's been replaced by something else).

Mac application note: NSApplication on the Mac always catches all Objective-C exceptions in the main run loop — so an exception on the main thread of a Mac application will not immediately crash the program, it will simply log the error. However, an unexpected exception can still leave the application in such a bad state that a crash will subsequently occur.

Catching uncaught exceptions

The correct way to handle an uncaught exception is to fix the cause in your code. If your program is working perfectly, then the approaches shown here should not be necessary.

Of course, programs do sometimes get released with bugs that may lead to a crash. In addition, you may simply want more information back from your testers when you know that there are bugs in your program.

In these cases, there are two ways to catch otherwise uncaught conditions that will lead to a crash:

• Use the function NSUncaughtExceptionHandler to install a handler for uncaught Objective-C exceptions.
• Use the signal function to install handlers for BSD signals.

For example, installing an Objective-C exception handler and handlers for common signals might look like this:

void InstallUncaughtExceptionHandler()
{
    NSSetUncaughtExceptionHandler(&HandleException);
    signal(SIGABRT, SignalHandler);
    signal(SIGILL, SignalHandler);
    signal(SIGSEGV, SignalHandler);
    signal(SIGFPE, SignalHandler);
    signal(SIGBUS, SignalHandler);
    signal(SIGPIPE, SignalHandler);
}

Responding to the exceptions and signals can then happen in the implementation of the HandleException and SignalHandler. In the sample application, these both call through to the same internal implementation so that the same work can be done in either case.

Save your data: The very first task to perform in your uncaught exception handler should be to save data that might need saving or otherwise clean up your application. However: if the exception may have left the data in an invalid state, you may need to save to a separate location (like a "Recovered Documents" folder) so you don't overwrite good data with potentially corrupt data.

While these cover the most common signals, there are many more signals that may be sent that you can add if required.

There are two signals which cannot be caught: SIGKILL and SIGSTOP. These are sent to your application to end it or suspend it without notice (a SIGKILL is what is sent by the command-line function kill -9 if you're familiar with that and a SIGSTOP is sent by typing Control-Z in a terminal).

Requirements of the exception handler

An unhandled exception handler may never return

The types of situations which would cause an unhandled exception or signal handler to be invoked are the types of situations that are generally considered unrecoverable in an application.

However, sometimes it is simply the stack frame or current function which is unrecoverable. If you can prevent the current stack frame from continuing, then sometimes the rest of the program can continue.

If you wish to attempt this, then your unhandled exception handler must never return control to the calling function — the code which raised the exception or triggered the signal should not be used again.

In order to continue the program without ever returning control to the calling function, we must return to the main thread (if we are not already there) and permanently block the old thread. On the main thread, we must start our own run loop and never return to the original run loop.

This will mean that the stack memory used by the thread that caused the exception will be permanently leaked. This is the price of this approach.

Attempt to recover

Since a run loop will be used to display the dialog, we can keep that run loop running indefinitely and it can serve as a possible replacement for the application's main run loop.

For this to work, the run loop must handle all the modes of the main run loop. Since the main run loop includes a few private modes (for GSEvent handling and scroll tracking), the default NSDefaultRunLoopMode is insufficent.

Fortunately, if the UIApplication has already created all the modes for the main loop, then we can get all of these modes by reading from the loop. Assuming it is run on the main thread after the main loop is created, the following code will run the loop in all UIApplication modes:

CFRunLoopRef runLoop = CFRunLoopGetCurrent();
CFArrayRef allModes = CFRunLoopCopyAllModes(runLoop);

while (!dismissed)
{
    for (NSString *mode in (NSArray *)allModes)
    {
        CFRunLoopRunInMode((CFStringRef)mode, 0.001, false);
    }
}

CFRelease(allModes);

As part of the debug information, we want the stack addresses

You can get the backtrace using the function backtrace and attempt to convert this to symbols using backtrace_symbols.

+ (NSArray *)backtrace
{
    void* callstack[128];
    int frames = backtrace(callstack, 128);
    char **strs = backtrace_symbols(callstack, frames);

    int i;
    NSMutableArray *backtrace = [NSMutableArray arrayWithCapacity:frames];
    for (
        i = UncaughtExceptionHandlerSkipAddressCount;
        i < UncaughtExceptionHandlerSkipAddressCount +
            UncaughtExceptionHandlerReportAddressCount;
        i++)
    {
        [backtrace addObject:[NSString stringWithUTF8String:strs[i]]];
    }
    free(strs);

    return backtrace;
}

Notice that we skip the first few addresses: this is because they will be the addresses of the signal or exception handling functions (not very interesting). Since we want to keep the data minimal (for display in a UIAlert dialog) I choose not to display the exception handling functions.

If the user selects "Quit" we want the crash to be logged

If the user selects "Quit" to abort the application instead of attempting to continue, it's a good idea to generate the crash log so that normal crash log handling can track the problem.

In this case, we need to remove all the exception handlers and re-raise the exception or resend the signal. This will cause the application to crash as normal (although the uncaught exception handler will appear at the top of the stack, lower frames will be the same).

Limitations

Attempting to recover from an arbitrary signal or exception has numerous problems that may prevent it working in many cases.

This approach won't work if the application hasn't configured the main run loop

The exact way that UIApplication constructs windows and the main run loop is private. This means that if the main run loop and initial windows are not already constructed, the exception code I've given won't work — the code will run but the UIAlert dialog will never appear. For this reason, I install the exception handlers with a performSelector:withObject:afterDelay:0 from the applicationDidFinishLaunching: method on the App Delegate to ensure that this exception handler is only installed after the main run loop is fully configured. Any exception that occurs prior to this point on startup will crash the application as normal.

Your application may be left in an unstable or invalid state

You cannot simply continue from all situations that trigger exceptions. If you're in the middle of a situation that must be completed in its entirety (a transaction on your document) then your application's document may now be invalid.

Alternately, the conditions which led to the exception or signal may have left your stack or heap in a state so corrupted that nothing is possible. In this type of situation, you're going to crash and there's little you can do.

The exception or signal could just happen again

The initial causes of the exception or signal will not be fixed by ignoring it. The application might simply raise the same exception immediately. In fact, you could become overwhelmed by exceptions in some cases — for this reason, I've limited the number of uncaught exceptions that may be handled to 10 in the sample application.

Resources used up to the time of the exception are leaked

Since the stack is blocked from returning, everything allocated on the stack or the autorelease pool between the main run loop and the exception will be leaked.

It might be bad behavior for the user

Depending on the style of your application, it might be better to simply let the crash happen — not all users care about debug information and your application might not have data that needs saving, so a very rare crash might not be too offensive.

gdb will interfere with signal handling

When you're debugging, the SIGBUS and SIGSEGV signals may not get called. This is because gdb inserts Mach exception handlers which picks them up at the EXC_BAD_ACCESS stage (and refuses to continue). Other signals type may also be handled by gdb, preventing the signals from reaching your handlers.

If you want to test signal handling properly, you'll need to run without gdb (Run with Breakpoints off).

Conclusion

You can download the sample project: UncaughtExceptions.zip (25kB)

It is possible to make your application resilient to crashes by handling common causes of exceptions and attempting to recover.

There are real risks though in terms of leaked memory and potentially corrupted application data, so this type of approach should be viewed as either a debugging tool or a measure of last resort.

However, it is comforting to have a level of fallback in the situation where a minor crash has slipped through your testing, provided you are cautious about your application's data and the presentation to the user is clear but not confusing.

Of course, the best way of handling exceptions remains: eliminate your bugs in the first place.

Introduction

This post will look at different ways to draw the following shape:

This is a very simple shape but it requires a non-simple topology: you must cut the center out of the shape to draw it. This post will look at 5 different ways that this can be done and the advantages or disadvantages with each.

To make the explanations easier, I've named each of the coordinates used to draw the shape:

// Coordinates are:
//
// A-------------B     A(0,0), B(100,0), C(100,100), D(0,100)
// |      E      |     E(50,10), F(10,90), G(90,90)
// |     / \     |     H(50,90), I(50,100)
// |    /   \    |
// |   /     \   |
// |  F---H---G  |
// D------I------C

Technique 1: overpainting

The most naive approach to drawing the shape is to draw the square (ABCD) in the shape's color and then draw the triangle (EFG) over the top in the color of the background.

To be clear though: this is an example of a technique that you should not use.

// Technique 1: overpaint
CGContextMoveToPoint(context, Ax, Ay);
CGContextAddLineToPoint(context, Bx, By);
CGContextAddLineToPoint(context, Cx, Cy);
CGContextAddLineToPoint(context, Dx, Dy);
CGContextAddLineToPoint(context, Ax, Ay);
CGContextSetRGBFillColor(context, 0.5, 0, 0, 1);
CGContextFillPath(context);
CGContextMoveToPoint(context, Ex, Ey);
CGContextAddLineToPoint(context, Fx, Fy);
CGContextAddLineToPoint(context, Gx, Gy);
CGContextAddLineToPoint(context, Ex, Ey);
CGContextSetRGBFillColor(context, 1, 1, 1, 1);
CGContextFillPath(context);

Advantages: if you're only familiar with the "painter's algorithm" (everything is just painted over the top of everything else) then this might be the easiest concept to understand.

Disadvantages: if your background changes, the effect won't work.

This approach also has the problem that the pixels within the triangle of the image are drawn twice in the offscreen buffer (once in the square's color and once in the background color). If you are drawing a very large number of shapes this way, this overdrawing will be slower than not drawing the center pixels in the first place.

Technique 2: false hole

Another attempt to cheat when drawing this shape would be to draw the shape as a single, simple polygon — i.e. cut the shape along the line segment between H and I and draw it like a horseshoe (ABCI then HGEFH then finish with IDA).

Again, this is an example of a technique that you should not use.

// Technique 2: false hole
CGContextMoveToPoint(context, Ax, Ay);
CGContextAddLineToPoint(context, Bx, By);
CGContextAddLineToPoint(context, Cx, Cy);
CGContextAddLineToPoint(context, Ix, Iy);
CGContextAddLineToPoint(context, Hx, Hy);
CGContextAddLineToPoint(context, Gx, Gy);
CGContextAddLineToPoint(context, Ex, Ey);
CGContextAddLineToPoint(context, Fx, Fy);
CGContextAddLineToPoint(context, Hx, Hy);
CGContextAddLineToPoint(context, Ix, Iy);
CGContextAddLineToPoint(context, Dx, Dy);
CGContextAddLineToPoint(context, Ax, Ay);
CGContextSetRGBFillColor(context, 0, 0.5, 0, 1);
CGContextFillPath(context);

Advantages: avoids the previous problem of the background being overdrawn in the wrong color.

Disadvantages : contains extra edges which won't draw correctly if you attempt to stroke the shape.

This approach can also suffer from precision problems: if the cut at the bottom does not actually overlap, it may be visible as a gap in the object when drawn at very high resolutions (for example on the Mac once resolution independence becomes user settable and objects can be drawn at unexpected sizes).

Technique 3: Winding count

This is the first of the correct approaches to drawing a hole in a path and uses the "winding count" polygon interior algorithm to label the inside of the triangle as "outside" the bounds of our path.

Winding count is the default way that CoreGraphics determines if a pixel is inside or outside a path. It works like this:

1. CoreGraphics draws every horizontal row within the path's bounding rectangle from left-to-right
2. At the start of each row, CoreGraphics sets the winding count for the shape to zero.
3. If CoreGraphics crosses a line in the shape at any point during the row, it notes if the line was going upwards or downwards at the point where CoreGraphics crossed it.
4. An upward line increases the winding count of the shape by 1.
5. A downward line decreases the winding count of the shape by 1.
6. If the winding count for the shape is ever non-zero (positive or negative) then pixels are filled according to the color of the shape.

If that's a little hard to follow then the simple description of winding count is:

Simple winding count: If a boundary is drawn clockwise, then a counter-clockwise boundary inside it will switch the shape off. If a boundary is drawn counter-clockwise, then a clockwise boundary inside it will switch it off.

This is how we use winding count to draw the shape:

// Technique 3: winding count fill rule
CGContextMoveToPoint(context, Ax, Ay);
CGContextAddLineToPoint(context, Bx, By);
CGContextAddLineToPoint(context, Cx, Cy);
CGContextAddLineToPoint(context, Dx, Dy);
CGContextAddLineToPoint(context, Ax, Ay);
CGContextClosePath(context);
CGContextMoveToPoint(context, Ex, Ey);
CGContextAddLineToPoint(context, Fx, Fy);
CGContextAddLineToPoint(context, Gx, Gy);
CGContextClosePath(context);
CGContextSetRGBFillColor(context, 0.5, 0.0, 0.75, 1);
CGContextFillPath(context);

The ABCD boundary is clockwise, so the counter-clockwise EFG creates a hole. To start the inner boundary, we just close the first boundary and move to the next (all boundaries become part of the current path).

Advantages: genuinely draws a shape with a hole cut out of it.

Disadvantages: accidentally draw the inner shape in the order EGF and it won't work (clockwise plus clockwise leads to a winding count of 2 — which is still non-zero and the shape will still be filled.

Winding counts require a little extra effort to ensure that directions are maintained at all times.

Technique 4: Even-odd paths

Even-odd is the other rule used for paths in CoreGraphics. The rule is a little simpler to explain than winding count: in even-odd, the outmost boundary begins the object, the next outermost turns it off again, and so on for other nested paths.

The code is very similar to the winding count version except that we fill using CGContextEOFillPath and the order of EFG with respect to ABCD does not matter.

// Technique 4: even-odd fill rule
CGContextMoveToPoint(context, Ax, Ay);
CGContextAddLineToPoint(context, Bx, By);
CGContextAddLineToPoint(context, Cx, Cy);
CGContextAddLineToPoint(context, Dx, Dy);
CGContextAddLineToPoint(context, Ax, Ay);
CGContextClosePath(context);
CGContextMoveToPoint(context, Ex, Ey);
CGContextAddLineToPoint(context, Fx, Fy);
CGContextAddLineToPoint(context, Gx, Gy);
CGContextClosePath(context);
CGContextSetRGBFillColor(context, 0.75, 0.5, 0, 1);
CGContextEOFillPath(context);

Advantages: less prone to ordering issues than winding count.

Disadvantages: there are some situations where winding count may give a better result. Consider the following pentagram drawn in a single continuous path 12345.

In this case, if you actually wanted to fill the center of the shape, you'd need to use winding count (the shape is drawn in a continuous clockwise direction so the winding count is always positive).

Technique 5: Clipping region

The final approach that I'll show is using a clipping region to remove the triangle at the center of the shape from the enabled drawing region.

// Technique 5: remove the inner hole using a clipping region
CGContextSaveGState(context);
CGContextAddRect(context, CGContextGetClipBoundingBox(context));
CGContextMoveToPoint(context, Ex, Ey);
CGContextAddLineToPoint(context, Fx, Fy);
CGContextAddLineToPoint(context, Gx, Gy);
CGContextClosePath(context);
CGContextEOClip(context);
CGContextMoveToPoint(context, Ax, Ay);
CGContextAddLineToPoint(context, Bx, By);
CGContextAddLineToPoint(context, Cx, Cy);
CGContextAddLineToPoint(context, Dx, Dy);
CGContextAddLineToPoint(context, Ax, Ay);
CGContextSetRGBFillColor(context, 0, 0, 0.5, 1);
CGContextFillPath(context);
CGContextRestoreGState(context);

You can see that this approach is actually quite complicated since a clipping region with a hole requires the same effort as a shape with a hole: I subtracted the triangle from the clipping region's bounding rectangle using an even-odd clipping rule.

Advantages: a clipping region can subtract or cut very complicated shapes — even clusters of shapes — very simply.

Disadvantages: for cutting a single shape like this, the extra effort required to save the old graphics state and restore it after we're done, plus the fact that the clipping region is just as complicated as the shape itself, makes this approach more effort than the previous two.

Conclusion

You can download the code for drawing these shapes here: GraphicalSubtraction.zip (25kB)

A very simple shape but you can draw it in some very different ways. As you can see, the "wrong" ways of solving the problem don't actually save any code — the proper solutions are roughly the same length.

The best ways to solve this problem are to use the even-odd or winding count approaches. While the shape might look like the center is clipped out, the clipping region turns out to be more work and non-rectangular clipping regions are actually more computationally difficult as well.
